Technical Advantage: The “Ceramization” Difference
While standard tapes melt or char, KAWIN’s ceramic silicone composite creates a sacrificial thermal barrier. It provides exceptional dielectric strength at temperatures where organic materials typically fail.
| Technical Property | Fiberglass Silicone Tape | KAWIN Ceramic Grade |
| Continuous Temp | 200°C – 260°C | 650°C (Stable) |
| Peak Excursion | 300°C | 800°C+ (Short term) |
| Flame Rating | UL 94 V-1 | UL 94 V-0 (Self-Extinguishing) |
| Arc Resistance | Moderate | Superior (Non-conductive Ash) |
| Flexibility | High | Excellent (High-Conformability) |
Critical Performance Features
Ceramicizable Adhesive System: At extreme temperatures, the silicone adhesive transitions into a ceramic layer. This ensures that even after the polymer burns off, the ceramic fiber remains bound to the substrate, providing continuous fire protection.
Low Thermal Conductivity: Acting as a precision thermal wrap, it minimizes heat transfer, protecting sensitive sensors and adjacent components in high-density industrial machinery.
Non-Toxic & Halogen-Free: Unlike traditional flame retardants, our ceramic tape does not release toxic fumes or corrosive gases during thermal decomposition—a critical safety factor for aerospace and marine applications.
Aggressive Pressure-Sensitive Bond: Formulated to stick to low-energy surfaces and oily metals commonly found in industrial furnace maintenance and automotive engine bays.
High-Stakes Application Scenarios
EV Battery Fire Mitigation: Used as a flame-retardant wrap between battery cells to prevent thermal runaway and provide localized firewalls.
Furnace & Kiln Door Sealing: Providing a flexible, high-temp gasket alternative that resists chemical vapors and constant thermal cycling.
Emergency Circuit Protection: Wrapping critical power and control cables in tunnels and high-rise buildings to ensure operation during active fires.
Aerospace Exhaust Wrap: Shielding hydraulic lines and wiring harnesses from intense radiant heat in jet engine compartments.
Bespoke Customization for Complex Engineering
We don’t just sell rolls; we provide engineered solutions:
Variable Thickness (0.3mm – 3mm): Thicker grades for heavy-duty insulation; ultra-thin grades for precision electronic wrapping.
Reinforced Scrim Options: Available with internal mesh reinforcement for applications requiring high-tension wrapping without elongation.
Adhesive Engineering: Custom tack levels (low-residue for temporary masking or high-shear for permanent bonding).
Die-Cut Precision: Custom gaskets, discs, and complex shapes with ±0.1mm tolerance for automated assembly lines.
FAQ
Q: Is ceramic silicone tape safer than asbestos tape?
A: Absolutely. Ceramic silicone tape is a 100% asbestos-free, non-toxic alternative. It provides superior thermal performance without the health risks associated with traditional mineral fibers.
Q: Can it be used as electrical insulation in high-voltage environments?
A: Yes. It offers excellent dielectric strength. Even if the tape is exposed to direct flame and “ceramizes,” the remaining mineral layer remains non-conductive, preventing short circuits during emergencies.
Q: How does it handle chemical exposure?
A: The ceramic fiber backing and silicone adhesive are highly resistant to industrial oils, mild acids, and most solvents, making it ideal for the chemical processing and automotive industries.
