Conductive Fabric Tape | EMI Shielding & Grounding Solutions

Conductive fabric tape is made of conductive fabric coated with conductive acrylic adhesive. It provides excellent EMI/RFI shielding, grounding, and conductivity, making it widely used in electronics, computers, and telecommunication devices. The tape features strong adhesion, flexibility, and easy die-cutting, ensuring stable performance in various industrial applications.

Key Features:

• Excellent EMI/RFI shielding effectiveness

• Strong adhesion with conductive acrylic adhesive

• High flexibility, easy to apply on curved surfaces

• Stable conductivity and low resistance

• Easy die-cutting for custom applications

Specifications:

• Product Code Technical Parameters	KN0403	KN0405	KN0407	KN0408	KN0410	KN0412	KN0415	KN0420	KN0426
  Color	Grey（Square/Plain）
  Total Thickness[mm]	0.03	0.05	0.07	0.08	0.1	0.12	0.15	0.2	0.26
  Backing Thickness[mm]	0.02	0.03	0.05	0.05	0.08	0.08	0.1	0.16	0.22
  Backing	Conductive Cloth
  Adhesive	Conductive Acrylic
  180°Peel Strength[N/inch]	8	10	12	12	12	12	12	12	12
  Initial Adhesion[#]	1	1	2	2	2	2	2	2	2
  Retentivity[hour]	48
  Surface Resistance[mΩ]	50
  Long-Term Temperature Resistance[℃]	80
  Short-Term Temperature Resistance[℃]	120

Applications:

• EMI/RFI shielding for electronic components

• Grounding in mobile phones, laptops, and communication devices

• Cable and connector shielding

• Anti-static and electrical conductivity solutions

• Industrial electronics assembly
