PE Protection Film
Conformable temporary protection for metal, plastic, glass and coated panels.
CUSTOM INDUSTRIAL TAPE SOLUTION
Custom Surface Protection Film Manufacturing
Build the solution around surface finish, application process, dwell time, removal force and residue risk, rather than specifying only a tape name or nominal thickness.
Quick answer: KAWIN customizes PE, PET and specialty protection films with controlled tack, color and print options. Material selection and converted presentation are aligned to the real component and production process.
CUSTOMIZABLE PRODUCT FORMS
What we can manufacture in this tape family
These options share one topic, but solve different engineering tasks. Select the closest form, then confirm the construction against your application.
PET Protection Film
Higher clarity and dimensional stability for displays, sheets and precision surfaces.
Co-Extruded Protection Film
Layered film construction where mechanical and adhesive behavior must be balanced.
Printed Protection Film
Logos, warnings, instructions and identification printed for OEM use.
Low-Tack Clean-Removal Film
Sensitive-surface protection with controlled peel and residue risk.
Die-Cut Protective Masks
Local masks, windows, tabs and shapes supplied on roll or sheet.
CONFIGURABLE PARAMETERS
Define the construction before defining the price
The quotation becomes meaningful only when the critical construction and delivery variables are known.
Primary decisionsurface finish, application process, dwell time, removal force and residue risk
MaterialsPE, PET and specialty protection films with controlled tack, color and print options
AdhesiveAcrylic, modified acrylic, silicone, rubber, conductive or specialty system as applicable
DimensionsThickness, width, length, pitch, shape and tolerances by drawing
PresentationRoll, sheet, spool, kit, kiss-cut roll or individual component
Quality recordApproved construction, drawing, packaging and inspection criteria
APPLICATION-LED SELECTION
Common decision situations
Use these scenarios to identify which details should be tested first.
Powder-coated metal
Texture and coating cure influence wet-out and removal force.
Polished stainless steel
Surface appearance makes residue, ghosting and edge lift visible.
Plastic sheet extrusion
Application temperature, line speed and winding tension affect film behavior.
Display and optical surfaces
Particle control, clarity and low contamination become critical.
Selection boundaries
- Higher tack is not always safer; it can increase residue or surface damage.
- Removal force changes with dwell time, temperature and aging.
- Test on the exact coating, gloss and surface texture.
RELATED CUSTOM SOLUTIONS
Only the closest engineering neighbors
These links prevent an isolated page without turning the page into a directory of unrelated tapes.
CUSTOM SURFACE PROTECTION FILM FAQ
Frequently asked questions
Protection film must survive processing while still removing cleanly from the finished surface.
How is the correct adhesion level selected?+
Adhesion should be high enough to resist lifting during fabrication and transport but low enough for clean removal. Surface energy, texture, coating, application temperature, forming operations, dwell time and peel conditions all need to be considered.
How can adhesive residue or ghosting be prevented?+
Use a film and adhesive matched to the surface and exposure period, then validate heat, UV, humidity, pressure and storage conditions. The surface must be stable and clean, and removal should occur within the approved process window.
Can protection film be printed for OEM use?+
Printing options can be reviewed for branding, handling instructions, directional marks or traceability. Artwork, ink compatibility, print repeat, film color, order quantity and whether printing contacts the protected surface should be confirmed.
Which dimensions and formats can be customized?+
Film thickness, adhesion, color, width, roll length, core, perforation, sheet size and packaging can be configured within material and equipment limits. Provide panel dimensions, application equipment and expected consumption when requesting a quotation.
Have a drawing, sample or performance target?
Send the substrate, dimensions, service conditions and estimated quantity. We will identify the missing variables before proposing a construction.
